Fixed Skylights
Looking for a specific size? Link to it in the below tables.
Mobile users swipe left on the table to see more sizes.
Fixed Skylight (FS) – Deck Mounted
| FS Size Code | A06 | C01 | C04 | C06 | C08 | C12 | D26 | D06 | M02 | M04 | M06 | M08 | S01 | S06 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Outside Frame (W"xH") | 15¼ x 46¼ | 21½ x 27⅜ | 21½ x 38⅜ | 21½ x 46¼ | 21½ x 54 1/16 | 21½ x 70¾ | 23¼ x 23 7/16 | 23¼ x 46¼ | 30 9/16 x 30½ | 30 9/16 x 38⅜ | 30 9/16 x 46¼ | 30 9/16 x 54 15/16 | 44¾ x 27⅜ | 44¾ x 46¼ |
| Rough Opening / Finished Frame (W"xH") | 14½ x 45¾ | 21 x 26⅞ | 21 x 37⅞ | 21 x 45¾ | 21 x 54 7/16 | 21 x 70¼ | 22½ x 22 15/16 | 22½ x 45¾ | 30 1/16 x 30 | 30 1/16 x 37⅞ | 30 1/16 x 45¾ | 30 1/16 x 54 7/16 | 44¼ x 26⅞ | 44¼ x 45¾ |
Fixed Skylight (FCM) – Curb Mounted
| FCM Size Code | 1430 | 1446 | 2222 | 2230 | 2234 | 2246 | 2270 |
|---|---|---|---|---|---|---|---|
| Inside Curb WxH (in) | 14½ x 30½ | 14½ x 46½ | 22½ x 22½ | 22½ x 30½ | 22½ x 34½ | 22½ x 46½ | 22½ x 70½ |
| Outside Curb WxH (in) | 17½ x 33½ | 17½ x 49½ | 25½ x 25½ | 25½ x 33½ | 25½ x 37½ | 25½ x 49½ | 25½ x 73½ |
| Maximum Skylight Clearance WxH (in) | 18⅝ x 34⅝ | 18⅝ x 50⅝ | 26⅝ x 26⅝ | 26⅝ x 34⅝ | 26⅝ x 38⅝ | 26⅝ x 50⅝ | 26⅝ x 73⅝ |
Fixed Skylight (FCM) – Curb Mounted (Continued)
| FCM Size Code | 3171 | 3030 | 3046 | 3422 | 3434 | 3446 | 4646 | 4672 |
|---|---|---|---|---|---|---|---|---|
| Inside Curb WxH (in) | 31½ x 71½ | 30½ x 30½ | 30½ x 46½ | 34½ x 22½ | 34½ x 34½ | 34½ x 46½ | 46½ x 46½ | 46½ x 72½ |
| Outside Curb WxH (in) | 34½ x 74½ | 33½ x 33½ | 33½ x 49½ | 37½ x 25½ | 37½ x 37½ | 37½ x 49½ | 49½ x 49½ | 49½ x 75½ |
| Max. Clearance WxH (in) | 35⅝ x 75⅝ | 34⅝ x 34⅝ | 34⅝ x 50⅝ | 38⅝ x 26⅝ | 38⅝ x 38⅝ | 38⅝ x 50⅝ | 50⅝ x 50⅝ | 50⅝ x 76⅝ |
